ASIA EXPRESS
FLAGKOREA
선박현황
| G/T |
4,007 |
 |
| DWT |
5,961 |
|
| LDT |
2,134 |
|
| NET |
2,014 |
|
| CALL SIGN |
DSNE5 |
|
| IMO NUMBER |
9129756 |
|
| OFFICIAL NUMBER |
JJR038890 |
|
| BUILT |
JULY, 1995 |
|
| BUILT'S NAME |
DAESUN SHIP BUILDING & ENGINRERING CO., LTD. |
|
| CLASS |
KR-9544758 |
|
| L/B/D |
98.00M / 17.20M / 8.30M(LOA : 107.00M) |
|
| DRAFT |
6.15M |
|
| MAIN ENGINE |
SSANGYONG B&W 7L35MC - 5,320PS X 1200RPM |
|
| SPEED AND CONSUMPTION |
AT SEA - ABOUT 14.8 KNOTS AT 14.0MT OF IFO 180 + 0.8 MT OF MDO
IN PORT - 0.8 MT OF MDO |
|
| TANK CAPACITY |
F.W.T 191.90 CBM
F.O.T 502.19 CBM
B.W.T 1,798.41 CBM
D.O.T 97.93 CBM
L.O.T 8.76 CBM
OTH.T 74.30 CBM
|
|
| CONTAINER INTAKE |
342 UNITS OF 20' X 8' X 8'6" |
|
| STOWAGE |
40/46/46 UNITS OF 20'
AT 1st/2nd/3rd TIER
IN HOLD (132 TEU),
17/23/23 FEU
72/74/64 UNITS OF 20'
AT 1st/2nd/3rd TIER
ON DECK (210TEU),
35/37/32 FEU
|
|
| REEFER RECEPTACLE |
40 UNITS (440V) |
|
| REMARKS |
|
FLAGKOREA
선박현황
| G/T |
8,570 |
|
| DWT |
12,839 |
|
| LDT |
3,732 |
|
| NET |
4,485 |
|
| CALL SIGN |
DSNH6 |
|
| IMO NUMBER |
9014119 |
|
| OFFICIAL NUMBER |
JJR-039373 |
|
| BUILT |
April, 1992 |
|
| BUILT'S NAME |
SHIN KURUSHIMA
DOCKYARD CO., LTD.
TAIHEI SHIPYARD,
AKITSU, JAPAN
|
|
| CLASS |
KR |
|
| L/B/D |
130.61M/ 21.80M / 10.75M(LOA : 139.14M) |
|
| DRAFT |
8.02M |
|
| MAIN ENGINE |
B&W 7L42MC/MCO - 5,970KW(8,120PS) AT 168RPM
CSO(90PCT OF MCO) - 5,375KW(7,310PS) AT 162RPM
|
|
| SPEED AND CONSUMPTION |
AT SEA - ABOUT 16 KNOTS AT 23.3 M/T OF IFO 180 + 1.5 M/T OF MDO(NO REEFERS)
IN PORT - 1.6 M/T OF MDO(IDLE)
|
|
| TANK CAPACITY |
F.W.T 457.47 CBM
B.W.T 4,323.77 CBM
F.O.T 1,054.56 CBM
D.O.T 124.78 CBM
LUB.O.T 59.00 CBM
|
|
| CONTAINER INTAKE |
700 UNITS X 20 X 8 / 8.6"
620 TEU / 14H HOMO |
|
| STOWAGE |
62/72/76/78 TEU
AT 1st-4th TIER IN HOLD
(288 TEU),
30/33/37/39 FEU (139 FEU)
114/114/114/70 TEU
AT 1st-4th TIER
ON HATCHES (412 TEU)
53/53/53/35 FEU (194 FEU)
|
|
| REEFER RECEPTACLE |
60 UNITS (440V) |
|
| REMARKS |
|
FLAGKOREA
선박현황
| G/T |
14,857 |
|
| DWT |
16,544 |
|
| LDT |
6,499 |
|
| NET |
5,397 |
|
| CALL SIGN |
DSQL8 |
|
| IMO NUMBER |
9181754 |
|
| OFFICIAL NUMBER |
JJR-092241 |
|
| BUILT |
October, 1998 |
|
| BUILT'S NAME |
NAIKAI ZOSEN, JAPAN
|
|
| CLASS |
KR |
|
| L/B/D |
152.02M / 26.20M / 13.20M(LOA : 161.96M) |
|
| DRAFT |
8.272M |
|
| MAIN ENGINE |
MAN B&W 6S42MC - 6,480 KW(8,820 PS) X 136 PRM
|
|
| SPEED AND CONSUMPTION |
19 KNOTS AT 46.8 M/T OF IFO 380 |
|
| TANK CAPACITY |
F.W.T 350.50 CBM
B.W.T 7,582.06 CBM
F.O.T 1,534.06 CBM
D.O.T 126.46 CBM
|
|
| CONTAINER INTAKE |
1,064 UNITS OF 20’ X 8’ X 8’6”,
960 TEU / 14T HOMO (Maximum load 1,060 units) |
|
| STOWAGE |
IN HOLD - 500 TEU, ON DECK - 564 TEU
|
|
| REEFER RECEPTACLE |
150 UNITS(440V) |
|
| REMARKS |
FITTED WITH BOW THRUSTER |
FLAGAntigua and Barbuda
선박현황
| G/T |
7,170 |
|
| DWT |
8,493 |
|
| LDT |
3,955 |
|
| NET |
3,068 |
|
| CALL SIGN |
V2DW2 |
|
| IMO NUMBER |
9532343 |
|
| OFFICIAL NUMBER |
4557 |
|
| BUILT |
FEB, 2010 |
|
| BUILT'S NAME |
zhejiang yangfang shipgroup co. ltd., china
|
|
| CLASS |
GL |
|
| L/B/D |
121.00M / 19.20M / 10.50M |
|
| DRAFT |
7.65 M |
|
| MAIN ENGINE |
MAN B&W 6L48/60B/7200KW/500RPM
|
|
| SPEED AND CONSUMPTION |
15 KNOTS AT 17M/T OF IFO 380
|
|
| TANK CAPACITY |
hfo abt 641.4 mts (0,98t/m3)
mgo abt 195,8 mts (0,86t/m3)
ballast water abt 3,821.6 mts (1,025t/m3)
fresh water abt 130.4 mts (1,00t/m3)
|
|
| CONTAINER INTAKE |
704TEU |
|
| STOWAGE |
in holds : 232 x 20' units
on deck/hatch : 472 x 20' units
|
|
| REEFER RECEPTACLE |
REEFER SOCKET 118 UNIT |
|
| REMARKS |
|
